Automatic Barrel-Wrap Packaging Machine for Drinking Water
A fully automated, food-grade barrel-wrapping solution engineered for bottled water producers — designed for seamless integration, precise operation, and long-term reliability in real-world production environments.
Highlights
- Fully automated barrel wrapping — no manual labor required
- Precision servo positioning and vacuum-assisted bag handling (≥99.8% success rate)
- Compliant with GB4806.9-2016 food-contact material standards
- Designed for plug-and-play integration with Chuxin Mingwei water filling lines
- Huizhou-based engineering & rapid local service response
Specifications
- Compatible Barrel Sizes
- 18.9L / 11.3L / 5L (diameter
- Rated Output Capacity
- 200–1,200 barrels/hour (based on 18.9L standard barrel)
- Packaging Film Requirement
- Food-grade PE or PP film, thickness 0.08–0.15 mm
- Sealing Method
- Adjustable-temperature hot sealing, seal width 10–15 mm
- Control System
- PLC + 7-inch HMI touchscreen with parameter memory and runtime statistics
- Frame Material
- 304 stainless steel structure, compliant with GB4806.9-2016
Smart, Integrated Barrel-Wrap Packaging for Water Production Lines
Chuxin Mingwei’s Automatic Barrel-Wrap Packaging Machine is purpose-built for drinking water manufacturers seeking consistent, hygienic, and high-efficiency secondary packaging. Unlike generic packaging equipment, this system is developed from deep experience in water filling line engineering — ensuring compatibility with common barrel formats, existing production infrastructure, and strict food safety requirements.
How It Works
The machine executes a complete packaging cycle: barrel conveyance → automatic bag pickup → servo-guided positioning → adjustable-temperature heat sealing → finished output. All stages operate without manual intervention, maintaining ISO-classified cleanliness and minimizing contamination risk during final packaging.
Key Application Scenarios
- New plant setup requiring turnkey water filling & packaging lines
- Automation upgrade of legacy barrel lines to improve throughput and reduce labor dependency
- Logistics center expansion needing reliable, high-speed shrink-wrap or PE sleeve application
Core Capabilities
Precision & Flexibility
- Supports standard barrel sizes: 18.9L, 11.3L, and 5L (diameter: 280–320 mm; height: 450–520 mm)
- Vacuum-assisted bag handling + mechanical guidance ensures ≥99.8% pickup success rate
- Servo-controlled positioning accuracy within ±5 mm
Food-Safe Sealing & Compliance
- Adjustable heat-sealing temperature (80–180°C), seal width 10–15 mm
- Seal strength ≥15 N/15 mm (meets GB/T 10004)
- All wetted parts made of GB4806.9-2016 certified 304 stainless steel
Operational Intelligence
- PLC + 7-inch HMI interface with real-time monitoring of output rate, success rate, and fault alerts
- Multi-profile parameter storage for quick format changeovers
- Optional UV disinfection module at bag opening (for enhanced microbial control)
System Integration Ready
This machine is engineered to interlock with Chuxin Mingwei’s full-line solutions:
- Barrel blow-dry units (to remove post-filling surface moisture)
- In-line date/batch coding systems
- Conveyor-linked automatic palletizing stations
- IoT-ready data acquisition modules (optional remote diagnostics & performance tracking)
Why Partner With Us?
We deliver more than hardware — we deliver context-aware engineering:
- Local responsiveness: Direct support from our Huizhou manufacturing base — including on-site layout assessment, physical barrel testing, and pilot-run validation
- Non-standard adaptability: Customized mechanical interfaces, control logic, and film-handling configurations based on your facility constraints and operational goals
- End-to-end ownership: From concept design and factory acceptance testing (FAT), through commissioning and operator training, to lifetime technical support and spare parts availability
