Clean Air Purification Systems
Custom-engineered air purification systems for water bottling and barrelled water filling cleanrooms — designed to meet ISO Class 8 (100,000) and higherstandards, integrated with your water treatment and filling line operations.
Highlights
- ISO Class 8 (100,000) certified design — upgradable to Class 7 (10,000)
- PLC + HMI control with real-time diagnostics and remote-ready interface
- Site-specific engineering: airflow, duct routing, and pressure zoning based on actual facility data
- Native integration with RO systems, ozone units, and filling lines
Specifications
- Filtration Efficiency
- H13 HEPA
- Airflow Range
- 1,500 – 20,000 m³/h (project-specific selection)
- Cleanroom Compliance
- ISO 14644-1 Class 8 standard; optional Class 7 configuration
- Control Interface
- Local PLC + 7" touchscreen HMI; Modbus RTU standard; optional MQTT/OPC UA
- Installation Options
- Ceiling-mounted, floor-standing, or modular wall-integrated layouts
Engineered Clean Air for Water Production Environments
Chuxin Mingwei’s Clean Air Purification Systems are purpose-built for beverage production facilities — especially bottled and barrelled water zones, RO/UF water treatment rooms, laboratories, and other controlled industrial environments. Unlike off-the-shelf HVAC units, our systems are non-standard engineered solutions: airflow volume, filtration staging, duct layout, pressure differential control, and integration logic are all determined from on-site measurements, target ISO class requirements, and operational constraints.
Why Clean Air Matters in Water Production
Airborne particles and microorganisms directly impact product sterility, packaging integrity, and regulatory compliance (e.g., GB 19304, FDA 21 CFR Part 129). Our systems ensure consistent airborne particle removal — supporting microbial control without relying solely on chemical disinfection.
Core System Capabilities
Three-Stage Filtration Architecture
- Pre-filter (G4): Captures coarse dust, hair, and fibers (>5 μm).
- Middle filter (F8): Removes fine particulates (1–5 μm), including mold spores and pollen.
- HEPA filter (H13): Delivers ≥99.95% efficiency for particles ≥0.3 μm — meeting ISO Class 8 and upgradable to Class 7 (10,000).
- Optional: Activated carbon module for VOC and odor control in high-humidity or adjacent processing areas.
Intelligent Air Management
- Variable-frequency fan control for precise airflow (1,500–20,000 m³/h), adjustable per zone size (50–500 m²).
- Dual-mode operation: constant airflow or constant pressure differential — configurable via PLC + HMI touchscreen.
- Real-time monitoring of filter differential pressure, system faults, and airflow status — with visual alerts and maintenance prompts.
Integration & Deployment Flexibility
Designed for seamless coordination with your existing infrastructure:
- Physical installation: Ceiling-mounted, floor-standing, or hybrid configurations — optimized for new builds or retrofit projects.
- Control integration: Native Modbus RTU/RS485 interface; optional OPC UA or MQTT for SCADA/MES connectivity.
- Process linkage: Synchronized start/stop with RO units, ozone generators, and filler machines to reduce energy waste and maintain stable pressure cascades.
End-to-End Cleanroom Support
As a full-scope water production partner, we deliver more than hardware:
- On-site cleanroom mapping and ISO classification validation (suspended particles, settle plates, airborne microbiology).
- Joint commissioning with water treatment and filling equipment — including cross-system alarm logic and interlock testing.
- Operator training, preventive maintenance scheduling, and spare parts logistics — backed by local Huizhou-based service response.
